Product Highlight

Efficient power delivery
Extended flight capability

Consumption Free Shipping by International Express (Excl. Remote Areas and Special Items).

Motor Type	HB-5308
Rated Voltage	6S LiPo (25 V)
Max Power (tested)	500 W
No-load Current	0.5 A
Max Current	30 A
Weight (incl. cable)	172 g
Configuration	12N14P
Stator Lamination	Japanese 0.2 mm steel
Copper Wire Rating	220°C high-temperature resistance
Cooling	Vortex cooling design (integrated)
Max Temperature	90°C
Typical ESC used in test	40 A Flame ESC

Type	Propeller	Throttle	Voltage (V)	Current (A)	Power (W)	RPM	Torque (N·m)	Thrust (g)	Efficiency (g/W)
380KV	1550 2-Blade	10%	25.11	0.16	4.1	915	0.01	32	7.82
		20%	25.10	0.52	13.0	1830	0.03	133	10.25
		30%	25.09	1.19	29.8	2643	0.06	298	10.00
		40%	25.05	2.41	60.4	3512	0.11	567	9.38
		50%	25.02	3.70	92.5	4115	0.16	806	8.71
		60%	24.95	6.13	152.9	4939	0.23	1210	7.91
		70%	24.86	8.97	223.0	5653	0.30	1612	7.23
		80%	24.76	12.25	303.3	6295	0.37	2014	6.64
		90%	24.64	16.30	401.6	6892	0.45	2451	6.10
		100%	24.52	20.01	490.7	7342	0.52	2819	5.75
	1604 2-Blade Foldable	10%	25.12	0.17	4.3	958	0.01	48	11.11
		20%	25.11	0.58	14.5	1817	0.05	185	12.72
		30%	25.09	1.42	35.7	2588	0.10	416	11.65
		40%	25.05	3.03	75.8	3435	0.16	766	10.11
		50%	25.00	4.75	118.8	4044	0.22	1075	9.05
		60%	24.92	7.85	195.6	4834	0.31	1546	7.90
		70%	24.82	11.33	281.1	5511	0.40	2017	7.18
		80%	24.69	15.50	382.7	6111	0.49	2481	6.48
		90%	24.51	21.74	532.8	6760	0.59	3049	5.72
		100%	24.32	27.81	676.3	7236	0.67	3468	5.13
	1758 2-Blade	10%	25.08	0.12	2.9	982	0.01	49	16.99
		20%	25.07	0.51	12.7	1828	0.04	198	15.61
		30%	25.05	1.30	32.6	2579	0.09	431	13.21
		40%	25.01	2.91	72.7	3388	0.16	811	11.15
		50%	24.95	4.82	120.2	3985	0.23	1157	9.62
		60%	24.86	8.08	200.8	4726	0.33	1668	8.31
		70%	24.75	11.99	296.7	5365	0.43	2168	7.31
		80%	24.59	17.60	432.6	6001	0.54	2733	6.32
		90%	24.37	25.01	609.5	6585	0.64	3255	5.34
		100%	24.19	30.35	734.3	6903	0.71	3591	4.89
